First record of the elusive oceanic squid Thysanoteuthis rhombus Troschel, 1857 (Cephalopoda: Thysanoteuthidae) in the Catalan coast

Fernando Ángel Fernández-Álvarez1, Ana I. Colmenero2 & Claudio Barría3

1 Ryan Institute and School of Natural Sciences, National University of Ireland Galway, Galway, H91 TK33, Ireland
Email: f.a.fernandez.alvarez@gmail.com — ORCID iD: https://orcid.org/0000-0002-8679-7377

2 Institut de Ciències del Mar, CSIC, Passeig Maritim de la Barceloneta 37–49, 08003 Barcelona, Spain
Email: colmenero@icm.csic.es — ORCID iD: https://orcid.org/0000-0003-2402-0922

3 Institut de Ciències del Mar, CSIC, Passeig Maritim de la Barceloneta 37–49, 08003 Barcelona Spain
Email: barria@icm.csic.es — ORCID iD: https://orcid.org/0000-0001-6769-4578



ABSTRACT

The diamondback squid Thysanoteuthis rhombus Troschel, 1857 is a large and elusive oceanic squid species. Here, we provide the first record of the species for the Catalan coast and integrate this finding in the current knowledge of the species in close areas.

Keywords: Mediterranean Sea; Cephalopoda; Oegopsida; Thysanoteuthidae; first record.



RESUMEN

Primera cita del elusivo calamar oceánico Thysanoteuthis rhombus Troschel, 1857 (Cephalopoda: Thysanoteuthidae) en la costa catalana

El chipirón volantín (Thysanoteuthis rhombus Troschel, 1857) es una especie de calamar oceánico grande y elusivo. En este trabajo se proporciona el primer registro de la especie para la costa catalana y se discute en el contexto de registros de la especie en zonas cercanas.

Palabras clave: Mar Mediterráneo; Cephalopoda; Oegopsida; Thysanoteuthidae; primera cita.



Recibido/Received: 13/04/2020; Aceptado/Accepted: 23/07/2020; Publicado en línea/Published online: 07/04/2021

Citation / Cómo citar este artículo: Fernández-Álvarez, F. A., Colmenero, A. I. & Barría, C. 2021. First record of the elusive oceanic squid Thysanoteuthis rhombus Troschel, 1857 (Cephalopoda: Thysanoteuthidae) in the Catalan coast. Graellsia, 77(1): e122. https://doi.org/10.3989/graellsia.2021.v77.284

Copyright: © 2021 SAM & CSIC. This is an open-access article distributed under the terms of the Creative Commons Attribution 4.0 International (CC BY 4.0).




CONTENTS

ABSTRACT

RESUMEN

Acknowledgements

References

The diamondback squid Thysanoteuthis rhombus Troschel, 1857 is a large oceanic squid, which reach a maximum mantle length of 1 m and 30 kg of total weight (Jereb & Roper, 2010). It is considered a cosmopolitan species distributed worldwide in tropical and temperate open waters. The rhomboidal fins are large and extend all the length of the mantle, giving to this species a characteristic diamond shape. T. rhombus is known in the Mediterranean Sea since the XIX century (Troschel, 1857); however, its oceanic lifestyle hinders its detection. Although it is a common species in Mediterranean waters (Biagi & Bello, 2009), records are scattered in the scientific literature.

During the night of the 29th August 2017 a specimen of T. rhombus was caught in the fishing grounds off the Catalan coast in the northwestern Mediterranean Sea (40.75527° N, 1.34805° E) at seafloor depth of 180 m, by the purse seine fleet from the Port of Tarragona. It was an immature subadult (Fig. 1A), measuring 93 mm mantle length and 33 g of total weight. Its sex was not possible to visually assess due the lack of detectable gonads at a macroscopic level. In Table 1, the dorsal mantle length, the ventral mantle length, the maximum mantle width, the fin length, the fin width, the head length, the head width, the length of the right arms I-IV and the right tentacle are provided according with the guidelines of Roper & Voss (1983). The characteristic well-developed anal photophore of juveniles and early subadults was present (Fig. 1B). The stomach content weighted 0.94 g and was entirely formed by fish fragments, including 3 vertebrae and 5 bones (0.37 g). Unfortunately, no otolith was recovered and the fish remain unidentified.

Fig. 1.—Thysanoteuthis rhombus Troschel, 1857. A. Dorsal and ventral views of the specimen ICMC000069 (CBR-ICM, Barcelona, Spain). B. Dissection showing the distal portion of the digestive system, the anal photophore (p) is near the anus (a).

Fig. 1.—Thysanoteuthis rhombus Troschel, 1857. A. Vistas dorsal y ventral del espécimen ICMC000069 (CBR-ICM, Barcelona, España). B. Disección mostrando la parte distal del sistema digestivo, el fotóforo anal (p) se encuentra cerca del ano (a).



Table 1.—Morphometric measures of the Thysanoteuthis rhombus Troschel, 1857 specimen ICMC000069 (CBR-ICM, Barcelona, Spain) according with Roper & Voss (1983).

Tabla 1.—Medidas morfométricas del espécimen ICMC000069 de Thysanoteuthis rhombus Troschel, 1857 (CBR-ICM, Barcelona, España) de acuerdo con Roper & Voss (1983).

Variable Value (mm)
Dorsal mantle length 93
Ventral mantle length 96
Maximum mantle width 39
Fin length 87
Fin width 98
Head length 24
Head width 25
Right arm I length 21
Right arm II length 45
Right arm III length 79
Right arm IV length 32
Right tentacle length 138

Some previous records of T. rhombus are known for the Iberian waters. The first one consisted in a single large individual fished in Mahón (Minorca) in 1978 (Morales, 1981), followed by the record of an egg mass by Guerra & Rocha (1997). Guerra et al. (2002) reported four additional egg masses in Mediterranean waters and other four in the Canary Islands. Escánez Pérez et al. (2012) reported several egg masses in the Canary Islands. Three large specimens were also reported in the Cantabrian Sea (Guerra et al., 2012). In the last work, it is also mentioned the capture of two individuals of both sexes in a tuna net in Ceuta. Templado and Luque observed two additional individuals in the Almeria coast (Guerra, 1992). For a comprehensive list of Catalonian and Iberian cephalopods, see Sánchez (2009) and Guerra (1992), respectively. Zaragoza et al. (2015) recorded 56 T. rhombus paralarvae sampled in 2004 and 2005. The presence of paralarvae at least during two consecutive years near the Ibiza Channel (Zaragoza et al., 2015), as well as the egg mass at the South of the Balearic Islands (Guerra & Rocha, 1997) and the newly reported subadult from Tarragona suggest that T. rhombus might be a common resident of the Balearic Sea. Besides those Iberian records, the species have been cited in other areas of the Mediterranean Sea (Issel, 1920; Sanzo, 1929; Biagi, 1982; Vardala-Theodorou et al., 1991; Jereb & Ragonese, 1994; Ezzeddine-Najai, 1996; Giordano et al., 1998; Bello, 1999; Salman et al., 2003; Marčic et al., 2009; Thessalou-Legaki et al., 2012; Yahel et al., 2017). Its oceanic lifestyle together with the absence of any target jigging fishery for oceanic squids in the area (Jereb & Roper, 2010) might complicate further encounters with this large oceanic squid. Despite its size and palatability, only a targeted fishery occurs in Japanese waters (Arkhipkin et al., 2015), but small catches are also reported in Jamaica, the Canary Islands and India (Aiken et al., 2007; Escánez Pérez et al., 2012; Sajikumar et al., 2020).

Material examined. Unsexed individual. 29/08/2017, at night. 40.75527° N, 1.34805° E. Fished by a purse seine vessel at surface waters (seafloor at 180 m of depth). M. Hernández leg. Voucher accession number ICMC000069, Biological Reference Collections of the Institut de Ciències del Mar (CBR-ICM, Barcelona, Spain), formalin fixed.


AcknowledgementsTop

Thanks to María Hernández (Confraria de Pescadors de Tarragona) for providing us with the T. rhombus specimen and the collecting data. Francisco Olivas performed the curation of the morphological voucher under the Biological Reference Collections (CBR-ICM). We thank two anonymous reviewers for their comments, which helped us to improve the quality of the manuscript. FAFA was supported by an Irish Research Council-Government of Ireland Postdoctoral Fellowship Award (Ref. GOIPD/2019/460).

ReferencesTop

Aiken, K., Kumagai, N., Yasuda, T. & Jones, I., 2007. The egg trace method of identifying diamondback squid fishing grounds in Jamaican waters. Proceedings of the Gulf and Caribbean Fisheries Institute, 59: 267–272.
Arkhipkin, A. I., Rodhouse, P. G. K., Pierce, G. J., Sauer, W., Sakai, M., Allcock, L., Arguelles, J., Bower, J. R., Castillo, G., Ceriola, L., Chen, C.-S., Chen, X., Diaz-Santana, M., Downey, N., González, A. F., Granados Amores, J., Green, C. P., Guerra, A., Hendrickson, L. C., Ibáñez, C., Ito, K., Jereb, P., Kato, Y., Katugin, O. N., Kawano, M., Kidokoro, H., Kulik, V. V., Laptikhovsky, V. V., Lipinski, M. R., Liu, B., Mariátegui, L., Marin, W., Medina, A., Miki, K., Miyahara, K., Moltschaniwskyj, N., Moustahfid, H., Nabhitabhata, J., Nanjo, N., Nigmatullin, C. M., Ohtani, T., Peel, G., Perez, J. A. A., Piatkowski, U., Saikliang, P., Salinas-Zavala, C. A., Steer, M., Tian, Y., Ueta, Y., Vrjai, D., Wakabayashi, T., Yamaguchi, T., Yamashiro, C., Yamashita, N. & Zeidberg, L. D., 2015. World Squid Fisheries. Reviews in Fisheries Science & Aquaculture, 23: 92–252. https://doi.org/10.1080/23308249.2015.1026226
Bello, G., 1999. New records of Thysanoteuthis rhombus (Cephalopoda: Thysanoteuthidae) in the Mediterranean Sea. Bollettino Malacologico, 34: 125–128.
Biagi, V., 1982. Sul rinvenimento di un giovane esemplare di Thysanoteuthis rhombus Troschel (Cephalopoda-Teutoidea) in acque elbane. Bolletino Malacologico, 18: 137–144.
Biagi, V. & Bello, G., 2009. Occurrence of an egg mass of Thysanoteuthis rhombus (Cephalopoda: Teuthida) in the Strait of Messina (Italy), locus typicus of the species. Bollettino Malacologico, 45: 35–38.
Escánez Pérez, A., Riera Elena, R., González González, Á.F. & Guerra Sierra, A., 2012. On the occurrence of egg masses of the diamond-shaped squid Thysanoteuthis rhombus Troschel, 1857 in the subtropical eastern Atlantic (Canary Islands). A potential commercial species? ZooKeys, 222: 69–76. https://doi.org/10.3897/zookeys.222.2835
Ezzeddine-Najai, S., 1996. On the presence of a new species of cephalopod Thysanoteuthis rhombus Troschel, 1857 on the north and south coasts of Tunisia. In: Oloriz F. & Rodrigues-Tovar F.J. (Eds.). 4th International Symposium Cephalopods – Present and Past. Department of Palaeontology, University of Granada: 64.
Giordano, D., Perdichizzi, F. & Greco, S., 1998. About a couple of Thysanoteuthis rhombus (Cephalopoda, Tysanoteuthidae) found in the Strait of Messina (Sicily). Rapports et procés-verbaux des réunions Commission internationale pour l'exploration scientifique de la Mer Méditerranée, 35(2): 436–437.
Guerra, A., 1992. Mollusca, Cephalopoda. In: Ramos, M. A. et al. (eds.). (Fauna Ibérica)., volumenI. Museo Nacional de Ciencias Naturales-CSIC. Madrid. 327 pp.
Guerra, A., González, A.F. & Laria, L., 2012. First records of the diamondback squid Thysanoteuthis rhombus in Asturian Waters (North Atlantic). Boletín de Ciencias Naturales IDEA, 52: 63–68.
Guerra, A., González, A.F., Rocha, F.J., Sagarminaga, R. & Cañadas, A., 2002. Planktonic egg masses of the diamond-shaped squid Thysanoteuthis rhombus in the eastern Atlantic and the Mediterranean Sea. Journal of Plankton Research, 24: 333–338. https://doi.org/10.1093/plankt/24.4.333
Guerra, A., & Rocha, F., 1997. On a floating egg mass of the diamond shaped squid Thysanoteuthis rhombus (Cephalopoda: Thysanoteuthidae) in the western Mediterranean. Iberus, 31: 125–130.
Issel, R., 1920. Primo contributo alla conoscenza dello sviluppo dei cephalopodi Mediterranei. Regio Comitato Talassografico Italiano. Memoria, 73: 1–19.
Jereb, P. & Ragonese, S., 1994. Su due grandi esemplari di Thysanoteuthis rhombus (Cephalopoda, Thysanoteuthidae), catturati a Mazaro del Vallo (Canale di Sicilia, Mediterraneo Centrale). Biologia Marina Mediterranea, 1: 289–290.
Jereb, R. & Roper, C.F.E., 2010. Cephalopods of the world. An annotated and illustrated catalogue of cephalopod species known to date. Vol. 2. Myopsid and Oegopsid Squids. FAO. Roma. 649 pp.
Marčic, Z., Ćaleta, M., Buj, I., Mrakovčić, M., Mustafić, P., Zanella, D. & Dulčić, J., 2009. First record of Thysanoteuthis rhombus (Cephalopoda: Thysanoteuthidae) in the Adriatic Sea. Marine Biodiversity Records, 2: e14. https://doi.org/10.1017/S1755267208000146
Morales, E., 1981. Presencia de Thysanoteuthis rhombus Troschel, en el puerto de Mahón (Menorca). Investigación Pesquera, 45(1): 17–20.
Roper, C. F. E. & Voss, G. L., 1983. Guidelines for taxonomic descriptions of cephalopod species. Memoirs of National Museum Victoria, 44: 49–63. https://doi.org/10.24199/j.mmv.1983.44.03
Sajikumar, K. K., Sasikumar, G., Venkatesan, V., Vidya, R., Alloycious, P. S., Jestin Joy, K. M., Karamathullah, P. S., Nataraja, G. D., Mohamed, K. S., 2020. Distribution, age and growth of the diamondback squid, Thysanoteuthis rhombus (Cephalopoda: Thysanoteuthidae) from the tropical Arabian Sea. Fisheries Research, 224: 105478. https://doi.org/10.1016/j.fishres.2019.105478
Salman, A., Katagan, T. & Avni Benli, H., 2003. Vertical distribution and abundance of juvenile cephalopods in the Aegean Sea. Scientia Marina, 67: 167–176. https://doi.org/10.3989/scimar.2003.67n2167
Sánchez, P., 2009. One century of teuthological records from the Catalan sea. Bolletino Malacologico, 45: 43–45.
Sanzo, L., 1929. Nidamento pelágico, uova e larve di Thysanoteuthis rhombus Troschel. Memorie Reale Corbitato Talassografico Italiano, 161: 1–10.
Thessalou-Legaki, M., Aydogan, O., Bekas, P., Bilge, G., Boyaci, Y., Brunelli, E., Circosta, V., Crocetta, F., Durucan, F., Erdem, M., Ergolavou, A., Filiz, H., Fois, F., Gouva, E., Kapiris, K., Katsanevakis, S., Kljajic, Z., Konstantinidis, E., Konstantinou, G., Koutsogiannopoulos, D., Lamon, S., Macic, V., Mazzette, R., Meloni, D., Mureddu, A., Paschos, I., Perdikaris, C., Piras, F., Poursanidis, D., Ramos-Esplá, A., Rosso, A., Sordino, P., Sperone, E., Sterioti, A., Taskin, E., Toscano, F., Tripepi, S., Tsiakkiros, L. & Zenetos, A., 2012. New Mediterranean Biodiversity Records (December 2012) Mediterranean Marine Science, 13: 312–327. https://doi.org/10.12681/mms.313
Troschel, F. H., 1857. Bemerkungen über die Cephalopoden von Messina. Archiv für Naturgeschichte, 23: 40–76.
Vardala-Theodorou, E., Giamas, P. & Dimitropoulos, A., 1991. A short notice on the occurrence of a pair of Thysanoteuthis rhombus Troschel, 1857 in southern Euboic Gulf. Bollettino Malacologico, 27: 25–34.
Yahel, G. K., Gilboa, R., Pilosof, M., Daya, M. A., Shefer, S. A. & Mienis, H. K., 2017. An egg mass of Thysanoteuthis rhombus from the Eastern Mediterranean off Israel. Triton, 36: 5–7.
Zaragoza, N., Quetglas, A., Hidalgo, M., Álvarez-Berastegui, D., Balbín, R. & Alemany, F., 2015. Effects of contrasting oceanographic conditions on the spatiotemporal distribution of Mediterranean cephalopod paralarvae. Hydrobiologia, 749: 1–14. https://doi.org/10.1007/S10750-014-2132-X
